CAR DROP-IN SCALES WITH A CONCRETE PLATFORM CB 100 TONS
The CB vehicle scales are equipped with a reinforced concrete platform. Such platforms are slightly more complicated to install, but car scales with platforms made of reinforced concrete have a greater safety margin and a longer service life than other car scales. If we compare the reinforced concrete construction of the SV with steel platforms, it wins in terms of economy. A concrete platform for automobile scales is made directly at the place of their future installation. The metal base of the platform is filled with concrete. Such scales are installed in the pit.
Features of car scales:
- Mounting unit on an elastomer support
- Steel pipes for cable laying
- Lightning protection
- Automatic identification of the label number
- Memory for 100,000 records
- Definition of transport with a permanent container
- Additionally 10 + 2 information fields
- Summary of reports for a certain period in a text file and for printing
- Defining the report format
- Data search by all criteria
- Connecting the printer
- Print labels and reports
- Compliance with metrological standards
- CE certificate
| ** Strain gauge | |
| Model | HSC |
| Degree of protection | IP68 |
| Mounting node | HSC-EL |
| Compensated operating range | -10 ° C … + 40 ° C |
| Operating temperature range | -40 ° C … + 80 ° C |
| *** Terminal | |
| Model | PWI-T |
| Degree of protection | IP54 |
| Supply voltage | 90-265 V AC 60 W |
| Operating temperature range | -10 ° C … + 40 ° C |
| Junction box J-Box | |
| Degree of protection | IP66 |
| Material | aluminum |
| Environment | |
| Compensated operating range | -10 ° C … + 40 ° C |
| Operating temperature range | -40 ° C … + 80 ° C |
| Supply voltage | 220V AC <300W (together with monitor and printer) |
* It is possible to set a double weighing interval.
** You can get data about strain gauges and mounting nodes used in scales in the catalog
*** You can get data about terminals used in scales from the catalog
